M17 Swan Nebula

Constellation: Sagittarius        Distance: 5000 lightyears

NGC6820

Click on image to toggle between HaRGB and Ha

Click for full resolution in HaRGB (2592 x 2163)
Click for full resolution Ha (3265 x 2487)

Image spcefications:
  • Exposure: 8 hours, HaLRGB = 180:210:30:30:30 minutes
  • Camera: SBIG ST-8300M, Temp -15 ° C, Baader LRGB filters
  • Instrument: TEC 140 with field flattener, focal distance 980 mm
  • Mount: Losmandy G11
  • Guiding: TS Off Axisguider, Starlight Xpress Lodestar autoguider and PHD
  • Location: Puimichel, France
  • Sky Quality Meter: between 21.10 and 21,21
  • Temperature Ambient: between 20° C and 24° C
  • Date: 22, 23 and 24 august 2011 (LRGB), 14 and 16 august 2012

Image acquisition with ImagesPlus 4.0 Camera Control (all at -15° C) with dither:
  • 9 H-alpha of 20 min, binned 1x1
  • 21 Luminance of 10 min, binned 1x1
  • 6 Red + 6 Green + 6 Blue of 5 min, binned 2x2
  • 20 Flat fields per channel with Aurora Flatfield panel
  • At home, camera in fridge:
  • 20 Dark frames of 20 min + 20 Dark frames of 10 min + 20 Dark frames of 5 min
  • 20 Flat darks (per channel) + 20 Bias frames

Processing in PixInsight 1.7
  • ImageCalibration, ImageIntegration, StarAlignment, ChannelCombination
  • BackgroundNeutralization, ColorCalibration, HistogramTransformation
  • LRGBCombination, ACDNR, CurvesTransformation, SCNR
  • HDRMultiScaleTransform, PixelMath
  • Ha and RGB combined with method Vincent Paris

Processing in Photoshop CS3:
  • Levels
