Image spcefications:
- Exposure: 8,5 hours, HaO3LRGB = 180:180:60:30:30:30
- Camera: ZWO ASI2600MM, Temp -10 ° C, Baader LRGB filters, Astrodon 5 nm Ha, 3nm O3
- Instrument: TEC 140, focal distance 980 mm
- Mount: Paramount MX+
- Guiding: TS Off Axisguider, Starlight Xpress Lodestar autoguider and PHD
- Location: Nozières, France
- Ambient temperature: round 21° C
- Date: 29 and 30 December 2024
- © Frans Kroon, Arno-MarkBlesgraaf
Image acquisition Sequence Generator Pro:
- 12 H-alpha of 15 min, binned 1x1
- 12 O3 of 15 min, binned 1x1
- 6 Lum of 10 min, binned 1x1
- 6 Red + 6 Green + 6 Blue of 5 min, binned 1x1
- 25 Flat fields per channel with Flatfield panel
- 20 Dark frames of 15 min + 20 Dark frames of 10 min + 20 Dark frames of 5 min + 50 Bias frames
Processed with PixInsight 1.8.9-2:
Lineair:
- ImageCalibration, CosmeticCorrection and StarAlignment
- ImageIntegration and ChannelCombination RGB
- GradiantCorrection on Ha, O3, Lum and RGB
- ImageSolver and SPCC on RGB
- BlurXTerminator on Ha, O3, Lum and RGB
Non Lineair:
- HistogramTransformation on Ha, O3, Lum and RGB
- NoiseXTerminator on Ha, O3, Lum and RGB
- Create StarImage of RGB with StarXTerminator
- LRGBCombination
- StarXTerminator on Ha, O3 and LRGB
- HDRMultiscaleTransform on starless LRGB
- NBRGBCombination on starless Ha, O3 and LRGB
- In Photoshop: make background sky dark (25:25:25) with Levels of result NBRGBCombination
- PixelMath to put them together: StarlessImage + StarImage
- SCNR
- HDRMultiscaleTransform
|
